Climatic test facilities enable necessary tests and approvals
Testing according to the majority of product standards and generic standards provides you with documentation demonstrating that your product can withstand relevant conditions.
Get all necessary climatic tests and approvals
In our climatic test lab, you can get all necessary tests and approvals handled by one project manager.
Verification according to all technical standards within climatic testing
We test and certify to nearly all technical standards within climatic testing and offer all types of accredited or guiding tests. Companies and organisations from all over the world come to us for climatic tests, thermal shock tests, corrosion tests, accelerated corrosion tests (HACT), slat spray tests, dust IP5X & IP6X, water IPX1-IPX9, free-falling dust tests, robustness tests (HALT and HASS), reliability tests (ALT and CALT), etc.
We are one of Scandinavia's leading technological service companies and carry out tests on several locations in Denmark, enabling easy access and visits.
Accredited by DANAK to perform testing and calibration
DANAK accredits us to perform testing and calibration. You can find a list of our accredited standards and CB Scheme standards on DANAK's website. We are also a CB test lab (CBTL) and a CB national certification body (NCB) that makes CB-certified reports. Find our list of CB standards on IECEE's website.
Unparalleled technical capacity; +20 climatic chambers of all types and sizes
More than 20 climatic chambers of varying types and sizes – some up to 896 m3 – enable us to conduct tests according to the majority of product standards and generic standards.
Contact us to find out how we can help you test your products to get documentation demonstrating that they can withstand relevant climatic conditions.
Temperature and humidity
Temperature and humidity chamberTemperature range: -100°C to +250°C
Humidity: 20 % RH to 98 % RH
Rate of change: 5 °C/min.
Dimensions 1-50 m3
Temperature changeFrom -100°C to +200°C, 5°C/min, though 60°C/min in HALT or 2-chamber method
Thermal shock testTemperature range: -80 °C to 220 °C
Rate of change: Less than 10 sec.
The effective volume (HxWxD): 40 x 46 x 60 cm
Thermal vacuum chamber1 m3, -40°C to +85°C, atmospheric pressure down to better than 1.3 x 10-3 Pa.
IP (Ingress Protection) equipment (solid foreign objects and water)
IP1X - IP6X testFor IP5X and IP6X max. size of test object (WxHxD): 2,000 x 1,000 x 900 mm
IPX1 - IPX9 testFlow: 100 l/min ±5 %
Test duration: 1 min. per m2, 3 min. minimum
Distance from nozzle: 2.5 - 3 m
Submersion depth: 1,000 mm
Duration: 30 min.
Customized solutions for larger object are available on request.
Corrosion chamberSO2, H2S
Salt mist chamberTemperature range: 23 °C to approx. +60 °C
Humidity range: 10%rh to 98 %rh
Salt concentration: can be adjusted but typically 5%NaCl
Dimensions external (LxHxD): 2035 x 1340 x 1150 mm
Dimension internal (LxHxD): 1200 x 850 x 800 mm
Test object weight max. approx. 300 kg
HALT and HASS
Dimensions: 1.06 x 1.06 x 1.01 m (LxWxH) 0.90 x 0.90 (table)
Temperature: -100 °C to +200 °C, up to 60 °C/min.
Vibration: 60-70 grms (10 Hz -20 kHz), 6-axis vibration
Artificial sunlight equipment (UV simulation)
Free-falling dust testTemperature range: 30 °C - 55 °C
Dimensions (HxWxD): 500 x 165 x 130 cm
Access (HxB): 190 x 93 cm
