Mechanical test facilities
World-renowned, accredited and certified testing and documentation demonstrate that your product can withstand the conditions to which it will be exposed during everyday use.
All types of accredited or guiding mechanical tests offered
We offer all kinds of accredited or guiding mechanical tests, such as vibration, robustness (HALT and HASS), reliability tests (ALT and CALT), ISTA®'s packaging test, transport tests, tensile and fatigue tests, compression tests, shock tests, inclination etc. In our mechanical test lab, you can get all the tests and approvals your business needs, all handled by a project manager.
Accredited test house you can trust
We are one of Scandinavia’s leading technological service companies and carry out tests in several locations, making access and visits easy. DANAK accredits us to perform testing and calibration, and you can see our accredited standards and CB Scheme standards on DANAK's website.
Also, we are a CB test lab (CBTL) and CB national certification body (NCB) and make CB-certified reports. You can find our list of CB standards on IECEE's website.
Mechanical testing facilities have unique technical capacity
- Our comprehensive mechanical testing facilities include both hydraulic and mechanical vibration shakers.
- We conduct all vibration tests, including resonance search, sinus, random and sine on random.
- We also perform vibration tests under temperature impacts from -70 ℃ to +180 ℃.
- Our electrodynamic shaker can test objects up to 1000 kg, depending on specifications.
- Our hydraulic shaker is capable of testing objects up to 2500 kg.
See below for further specifications of our mechanical testing facilities,or contact us to find out how we can help you demonstrate that your product can withstand relevant conditions.
Technical capacity in our test facilities
Electrodynamic shakersFrequency range: 1-3000 Hz
Effect: 35.6 kN
Acceleration: 112 g (sine peak), 100 g (random rms)
Velocity sine peak: 1.8 m/s
Displacement: ± 37.1 mm / 1.5”
Combined vibration and temperature: -70 °C to +180 °C
Hydraulic shakerFrequency range: 1-300 Hz
Displacement: < 100 mm
Force: < 145000 N (33000 pound-force)
Fixture area: 1520 x 1520 mm (60 x 60")
Test sample: < 2.5 t
Shock machineHalf sine shock max. acceleration: 3000 g
Duration: Amplitude x duration < 1000
Max load: 90 kg
Electrodynamic shaker with slip tablePower: 36 kN and 35,6 (sine peak)
Frequency range: 1-3000 Hz
Max. amplitude: 100 g
Duration: Amplitude x duration < 570
Velocity sine peak 1,8 m/s,
Displacement: ± 0,5-1,5”
Drop testHeight: up to 2 metres
Impact surfaces: wood, concrete or steel
Max load 3 T
Spring hammers0.5 Nm and 1.0 Nm
HALT and HASS
Dimensions: 1.06 x 1.06 x 1.01 m (LxWxH) 0.90 x 0.90 (table)
Temperature: -100 °C to +200 °C, up to 60 °C/min.
Vibration: 60-70 grms (10 Hz -20 kHz), 6-axis vibration
Tensile and fatigue test
Fatique10 N to 50 kN
Temp: -100 °C to +350 °C
Frequencies up to 30Hz
Tensile & Compression0.1 N to 100 kN
Temp: -100 °C to +350 °C
